The benefits of the Gerber X2 format
Perfectly understanding customer data and not losing any PCB design information in data transfer, are key issues to seemlessly produce and deliver quick turn around PCB prototypes.
In our BLOG section we already explained the history of the Gerber Format. We have written a white paper on which actions we need to perform once we have received your data to check them and make them production ready. And we have informed you that UCAMCO is no longer supporting the old Gerber RS-274D format.
Gerber X2 is todays” standard. Why should you use it?
X2 adds intelligence to the Gerber format by its use of attributes. When PCB Vislualizer processes your new job, attributes allow the software to put the layers directly in the correct position in the stack-up. Other attributes identify the via pads, the SMD pads and so on. This avoids manual interaction and offers extra info for DRC and DFM checks. UCAMCO”s Gerber X2 intro movie offers a sneak preview in the CAM-engineers environment where he uses a UCAM system reading in X2 and experiencing its benefits.
CAD systems – KiCAD, Pulsonix, Easy-PC, DipTrace and Altium – can all generate Gerber X2 files. UCAMCO cooperated with the CAD and other software vendors to validate their X2 output. We like the efficiency of X2, please use it as It will improve data transfer from you to us in a safe and practical way.
All about the Gerber format on the UCAMCO website
