Simplify advanced PCB design with HDI pool

Today’s electronic designs are rapidly shrinking – components such as micro-BGAs and CSPs (Chip Scale Packages) are becoming common even in everyday industrial applications. However, integrating these smaller components often pushes traditional PCB manufacturing to its limits. Eurocircuits’ HDI Pool Service bridges this gap by providing an efficient and cost-effective method to incorporate advanced features typically available only with expensive, fully custom HDI (High Density Interconnect) PCBs.

If moving to HDI technology seems complex or intimidating, it doesn’t have to be. Eurocircuits’ HDI pool service makes adopting HDI technology straightforward and accessible, even if you are new to microvias and advanced PCB techniques.

HDI simplified

High-Density Interconnect (HDI) technology, especially microvias, offers excellent solutions for integrating micro-BGAs (down to 0.4 mm in your PCB design). Read more: start designing with HDI.

It also minimises via stubs, significantly improving signal integrity for high-speed digital applications.

If you are working with QFN components or other thermally demanding packages, HDI helps manage heat effectively, enhancing component reliability through thermal decoupling.

Practical benefits without complexity

The beauty of Eurocircuits’ HDI pool Service lies in its simplicity and practicality. Rather than committing fully to the complex and costly HDI processes, you can select partial HDI features tailored specifically for your needs:

• Predefined stack-ups: Choose between a 6-layer or 8-layer stack-up with staggered microvias on two layers.
• Fast and cost-effective: Benefit from quick production times – your PCBs can be ready in just 10 working days.
• Instant online pricing and feedback: Eurocircuits’ Visualizer tool provides immediate Design Rule Checks (DRC), Design for Manufacturing (DFM) feedback, and pricing.

Reliable results right from the start

Reliability matters. Eurocircuits ensures your prototypes come out Right-First-Time through rigorous design validation and production processes. Plus, our dedicated expert engineering support guides you through critical steps such as micro-BGA fan-outs, ensuring your designs are robust and manufacturable.

Seamless integration into your workflow

With our Dedicated DRC-rules for all CAD tools is straightforward, speeding up your design cycle significantly.

Whether you are designing for industrial electronics, IoT devices, or high-speed digital applications, Eurocircuits takes you by the hand, easing your transition into HDI technology.

Discover how easy HDI can be: cost-effective, fast, and reliable. Let Eurocircuits’ HDI pool Service simplify your next advanced design.
